This is the nlight relay pack.
Nlight line voltage dimming.
Explore our best in class lighting control products today.
Each unit has two important responsibilities.
Nlight provides the industry s leading lighting controls systems and lighting control products.
Nlight is your network lighting controls system with wired or wireless options that is easy to specify install and use that grows with your business today and tomorrow.
Low voltage lighting typically uses 12 or 24 volts and requires a transformer to lower the line voltage from 120 volts to avoid immediately burning out the.
Phase control dimming module by nlight the pcdm dimming control module takes a 0 10v dimming signal and a fixed line voltage input and converts it to a reverse phase dimmed output for up to 1000w with a 277v load and 450w on a 120v load.
Wallpods with the dx dimming option have the added ability to adjust the level of any nlight controlled dimmable lighting.
The pcdm phase control dimming module takes a 0 10v dimming signal and a fixed line voltage input and converts it to a reverse phase dimmed output for up to 1000w with a 277v load and 450w on a 120v load.
Line voltage is the standard voltage 120 volts that s found in outlets and junction boxes in the united states and canada.
To provide system power the power pack transforms class 1 line voltage 120 277 vac or 347 vac to class 2 15 vdc.
Switching dimming 3 wire mlv loads.
The nwsx lv nwsx pdt lv series nlight wall switch occupancy sensor provides a simple control solution for a small room in particular one utilizing nlight enabled digital luminaires.
For this line voltage fixtures are basically plug and play.
The nlight nsp5 pcd series secondary relay and dimming pack is capable of switching and dimming incandescent lighting loads certain line voltage dimmable fluorescent lighting loads magnetic low voltage mlv lighting loads and electronic low voltage elv lighting loads.
The nlight npp16 series power pack is the workhorse of an nlight system.
For push button scene control see the npodm 1s 2s 4s series wallpods.
Capable of detecting small motion up to 20 ft 6 10 m this sensor is perfect for private offices private rest rooms copy rooms closets or any small enclosed.
With nlight you can control indoor and outdoor spaces seamlessly while reducing energy costs aiding in building code compliance improving occupant comfort and much more.
We ve introduced the capability to do phase dimming on the nlight lighting controls platform for either wired or wireless all on one system.
A basic low voltage wallpod can work with an nlight power pack or line voltage sensor to provide toggle switch operation.
